Spare Axle Mount Kit — UTV Roll Cage
True 1:1 template kit - Spare Axle Mount Kit — UTV Roll Cage: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: MEASURE YOUR SPARE AXLE SHAFT DIAMETER AGAINST DIA 1.000in BEFORE CUTTING - SHAFTS VARY, DESIGN SPEC VERIFY ON VEHICLE: CONFIRM CAGE TUBE OD IS 1.750in BEFORE CUTTING - CLAMP STRAPS ARE DEVELOPED FOR 1.750in TUBE; CONFIRM AXLE/CV CLEARANCE TO THE BED + ROOF
One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
