Cross Kart Frame Kit — Complete Build

Complete cross kart frame build kit — 4 blueprint sheets: side, top and front frame views, a jig table with true 3D tube lengths, an equal-tube saddle wrap, and five plates drawn at 1:1 (engine plate, axle hangers with 2.50in bore, spindle brackets, seat tabs, pedal plates) with pure-geometry DXF cut files. Full tube cut list with lengths computed from the 3D frame geometry. Hoop splay reading is stated on the sheet: floor +/-9in to main top +/-20in is the reading under which the frame's stated 40.00/38.00in crossbars land exact — true lengths therefore run longer than flat 2D numbers, and the sheet says so. True 1:1 scale on 9x11 tiled sheets with assembly key and print-check squares. VERIFY BEFORE CUTTING: seat fit, engine plate (match-drill to your engine) and steering toe are design spec — confirm seat and driver clearance before final weld.
