Belt Guard Kit — Alley Sweeper Mini Bike
True 1:1 template kit - Belt Guard Kit — Alley Sweeper Mini Bike: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: MEASURE YOUR DRIVEN PULLEY DIAMETER AGAINST DIA 7.000in BEFORE CUTTING - CONVERTERS VARY, DESIGN SPEC VERIFY ON VEHICLE: CONFIRM COVER HOLES MATCH YOUR ENGINE PLATE BEFORE CUTTING - MATCH-DRILL TO YOUR PLATE, DESIGN SPEC; CHECK BELT CLEARANCE AT FULL TRAVEL
One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
