Tire Pump Mount Kit — Alley Sweeper Mini Bike
True 1:1 template kit - Tire Pump Mount Kit — Alley Sweeper Mini Bike: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: CONFIRM YOUR PUMP BODY DIA IS 1.500in BEFORE CUTTING - CRADLE BANDS ARE DEVELOPED FOR 1.500in, PUMPS VARY VERIFY ON VEHICLE: CONFIRM FRAME TUBE OD IS 1.250in + PUMP CLEAR OF CHAIN / LEG BEFORE CUTTING - DESIGN SPEC
One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
