Triple Link Suspension — Main Crossmember Layout Template

Download and print this precision triple link suspension template. Triple Link Suspension — Main Crossmember Layout Template — print-ready 1:1 scale, print at home on any printer. Instant digital download.

• Full 1:1 scale crossmember layout — tape to table, mark tube positions
• Shows bracket hole positions, gusset locations, and tube centerlines
• Eliminates manual measurement errors on the most complex part of a 3-link build
