Magnet Sweeper Kit — Pro Welding Shop + Workbench
True 1:1 template kit - Magnet Sweeper Kit — Pro Welding Shop + Workbench: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY BEFORE CUTTING: MEASURE YOUR MAGNET BAR BEFORE CUTTING - THE 18.000 x 2.500in HOUSING IS DESIGN SPEC, MAGNET BARS VARY. MAGNET BAR BUILDER-SUPPLIED, MUST SLIDE IN THE HOUSING WITH NO RATTLE VERIFY: WHEELS MUST RUN TRUE AND THE RELEASE PLATE MUST DROP THE LOAD CLEAR WHEN LIFTED - TEST OVER SCRAP BEFORE FIRST FLOOR USE. KEEP THE MAGNET AWAY FROM PHONES, CARDS AND PACEMAKERS - DESIGN SPEC
One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
