Brute Force Complete Mod Plan Bundle
$49
Instant digital download • 5 plans in one bundle
Full DIY mod plan set for the Kawasaki Brute Force 750. Includes snorkel routing plan, radiator relocation bracket DXF, vent line routing diagram, oil cooler mounting bracket DXF, and fan override wiring diagram. Everything to prep your BF750 for serious trail riding or water crossings.
Fits2005–2023 KVF750
Plans5 in bundle
DXF Files2 included
FormatPDF + DXF
Everything in the Bundle
✓
Snorkel Routing Plan
Full layout with tube sizes, routing path, and airbox adapter notes.
✓
Radiator Relocation Bracket DXF
CNC/plasma-ready. 1/8" mild steel. Bolt-on design.
✓
Vent Line Routing Diagram
All differentials and gearcase. Never lose fluid to submersion.
✓
Oil Cooler Mounting Bracket DXF
Fits 4" universal oil cooler. 1/8" mild steel.
✓
Fan Override Wiring Diagram
Full-color relay circuit. Relay part numbers included.
Who This Is For
BF750 owners prepping for deep water crossings
Trail riders tired of overheating and submerged diffs
Weekend builders who want all five mods done in one go
Anyone who's spent hours on forums looking for real plans
