Roll Cage Sandwich Plate Kit — UTV Roll Cage

True 1:1 template kit - Roll Cage Sandwich Plate Kit — UTV Roll Cage: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: MEASURE YOUR CAGE TUBE OD, CHASSIS RAIL AND FLOOR BEFORE CUTTING - THE 1.750in TUBE HOLE, 6.000 x 4.000in PLATES AND 4.500 x 2.500in BOLT PATTERN ARE DESIGN SPEC, CAGES AND CHASSIS VARY VERIFY ON VEHICLE: TOP AND BOTTOM PLATES MUST CLAMP FLAT WITH NO GAP OR CRUSHED FLOOR MATERIAL, ALL 4 THROUGH-BOLTS MUST BE GRADE 8 WITH LOCK NUTS, AND THE CAGE FOOT MUST SIT FULLY ON THE TOP PLATE BEFORE DRIVING - DESIGN SPEC
