Rear Hub Guard Kit — Cross Kart + Buggy Build
True 1:1 template kit - Rear Hub Guard Kit — Cross Kart + Buggy Build: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: MEASURE YOUR REAR HUB BORE, AXLE NUT AND BOLT PATTERN BEFORE CUTTING - THE GUARD BORE AND PATTERN ARE DESIGN SPEC, KART HUBS AND AXLES VARY VERIFY BEFORE DRIVING: GUARD MUST CLEAR THE CHAIN, BRAKE DISC AND TYRE AT FULL TRAVEL WITH NO CONTACT ON ANY ROTATING PART, AND THE AXLE NUT MUST STAY FULLY TIGHT UNDER THE GUARD - DESIGN SPEC
One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
