Toe Plate Setup Kit — Cross Kart + Buggy Build

True 1:1 template kit - Toe Plate Setup Kit — Cross Kart + Buggy Build: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: MEASURE YOUR TIRE DIA AND HUB FACE BEFORE USE - THE 24.000 x 6.000in TOE PLATES ARE DESIGN SPEC SETUP TOOLS, KART TIRES AND TRACK WIDTHS VARY. PLATES MUST SIT FLAT AND SQUARE ON BOTH FRONT TIRES AT RIDE HEIGHT WITH THE DRIVER WEIGHT IN THE SEAT VERIFY BEFORE RACING: SET TOE WITH THE STRING LINES PARALLEL TO THE REAR AXLE LINE, RE-CHECK AFTER ANY TIE-ROD OR SPINDLE CHANGE, AND REMOVE THE PLATES BEFORE THE KART MOVES - SETUP TOOL ONLY, NEVER DRIVE ON THEM - DESIGN SPEC
