24x4 Fixture Table End Strip Hole Pattern (5/8" holes, 2" spacing)
End strip hole pattern for the 24x48 fixture plate top (sold separately): 11 holes, 0.625in (5/8in) diameter, single center row on a 24x4in strip, 2.00in on-center with the first hole 2.00in from each end — the same grid as the top plate edge row, so clamps and fixtures line up around the corner of the table. Print at 100%, trace or center-punch onto steel strip, drill or CNC-cut. Print twice for both ends. Layout template only — strip thickness by builder.
Metric: Width 609.6 mm · Height 101.6 mm · Hole Ø 15.9 mm
