Seat Templates
Mini Bike Build - Seat Pan & Fender Blanks
Seat pan and fender blanks for the Mini Bike Build, true 1:1. The seat pan flat pattern runs 17.00in long with 0.75in fold-down flanges, a 20-degree rear kick-up and four mount holes. Rear fender blank: 15.50 x 7.00in, forms over an R8.00 radius at a 110-degree arc. Front fender blank: 12.00 x 6.25in, R8.00 form, 85-degree arc. A form-data table on the sheet ties every blank to its finished shape. Ships as a print-ready tiled PDF (11 pages, Letter size, 0.5in overlap, numbered tiles with an assembly key) - print at 100% and tape the pages together.
One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
