Tank Bag Mount Kit — Alley Sweeper Mini Bike
True 1:1 template kit - Tank Bag Mount Kit — Alley Sweeper Mini Bike: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: CONFIRM TANK BAG FOOTPRINT FITS THE 8.000 x 5.000in TRAY AREA BEFORE CUTTING - DESIGN SPEC VERIFY ON VEHICLE: CONFIRM FRAME TUBE OD IS 1.250in + TANK / CAP CLEARANCE BEFORE CUTTING - DESIGN SPEC
