1.25" Fishmouth Saddle Wrap Stencil (1.25" onto 2", 90°)

Name: 1.25" Fishmouth Saddle Wrap Stencil (1.25" onto 2", 90°)
Price: 1.0 USD
Availability: InStock

Printable wrap stencil for a true fishmouth (saddle) cope: 1.25in OD branch tube joining a 2in OD main tube at 90 degrees, centerlines intersecting. Unwrapped cut curve computed from the cylinder-intersection formula depth = R - sqrt(R^2 - (r cos t)^2) with r = 0.625in, R = 1.0in: wrap width 3.927in (pi x 1.25in circumference), max cut depth 0.219in, seam ticks every 45 degrees, and a 1in scale-check square. True 1:1 scale at 96 DPI - print at 100%, wrap, trace the red curve, cut. Pure tube geometry - no vehicle fit involved. Works with any wall thickness (fits on OD). Test-fit on scrap first.

Metric: Branch OD 31.8 mm · Main OD 50.8 mm · Wrap width 99.7 mm

One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
