Angle Plate Fixture Kit — Pro Welding Table + Workbench

True 1:1 template kit - Angle Plate Fixture Kit — Pro Welding Table + Workbench: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY BEFORE CUTTING: CONFIRM YOUR BENCH / TABLE HOLE PATTERN BEFORE DRILLING - THE 0.500in FIXTURE HOLES ON 2.000in CENTRES ARE A DESIGN SPEC SHOP PATTERN, TABLES VARY VERIFY: THE VERTICAL FACE MUST BE CHECKED SQUARE TO THE BASE WITH A MACHINIST SQUARE AFTER WELDING AND BEFORE USE AS A FIXTURE, WELDS MUST BE GROUND CLEAR OF BOTH FACES, AND THE PLATE MUST BE CLAMPED - NEVER HAND-HELD - UNDER LOAD - DESIGN SPEC
