Bumper Plans
UTV Front Bumper Fabrication Plan Set
$59
Instant digital download • DXF cut files + PDF build plans
DXF cut files plus PDF build plans for a welded UTV front bumper. Fits Polaris RZR XP 1000. Includes bend diagrams, weld sequence instructions, hardware list, and SendCutSend-ready files. Everything you need to build a clean, functional front bumper from scratch.
FitsPolaris RZR XP 1000
Material3/16" + 1/8" mild steel
FormatDXF + PDF
Files6 items
What's Included
✓
Front Bumper Face DXF
Main impact face plate, plasma-ready. 3/16" mild steel.
✓
Wing Plates DXF (x2)
Left/right wrap-around wing pieces. 1/8" mild steel.
✓
Mounting Tab DXF
Frame-mount tabs with pre-drilled factory bolt pattern.
✓
PDF Bend Diagram
All bend lines, radii, and angles labeled and color-coded.
✓
PDF Weld Sequence
Step-by-step weld order with distortion control notes.
✓
Hardware List
All bolts, nuts, and washers with part numbers.
Who This Is For
RZR XP 1000 owners tired of flimsy factory plastic
Fabricators who want accurate plans, not vague forum posts
Anyone who wants a custom bumper without the shop markup
Builders using SendCutSend to outsource plate cutting
