Mini Bike Build - Complete Package (All Sheets + TAV Backing Plate)
The whole Mini Bike Build in one download: all nine 1:1 template sheets plus the integrated 30-series TAV backing plate. Frame geometry and jig layout, the tube cut list and bend table, engine cradle and gusset plates, rear axle hangers, forks and triple clamps, handlebar bend table, gas tank flat pattern, 60T #420 rear sprocket, seat pan and fender blanks - one original PunchMapPro design, every sheet dimensioned to work together. Every sheet ships as a print-ready tiled PDF with numbered tiles and an assembly key; print at 100% and check each sheet's 1.00in print-check square. Five sheets carry VERIFY ON VEHICLE flags, printed on the drawings - read the notes before cutting.
One payment unlocks every template on the site — yours forever. After checkout you land in your library with everything ready to download.
