Door Limiter Kit — UTV Roll Cage
True 1:1 template kit - Door Limiter Kit — UTV Roll Cage: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: MEASURE YOUR CAGE TUBE OD AND DOOR OPENING BEFORE CUTTING - THE ARC SLOT RADIUS 6.000in, 1.750in STRAP AND PLATE SIZES ARE DESIGN SPEC, CAGES AND DOORS VARY VERIFY ON VEHICLE: LIMITER MUST STOP THE DOOR BEFORE IT STRIKES ANY BODYWORK, TIRE OR BYSTANDER, THE SLOT BOLT MUST SLIDE FREE THROUGH THE FULL ARC WITH NO BIND, AND THE DOOR MUST STILL LATCH FULLY CLOSED BEFORE DRIVING - DESIGN SPEC
