Tube Bender Plans — Heavy-Duty Shop Bender Build Kit

Complete build plans for a heavy-duty shop tube bender — 3 blueprint sheets: side view with swing arm and die in working position, front view, top view, and a true 1:1 plate sheet. Die seat plate 8 x 8 x 1/2in with a degree ring laid out by trig (R3.25in, 5-degree ticks, 0-120 degrees), cheek plates, full tube cut list and hardware list on the sheets. Pure-geometry DXF cut files for both plates included. True 1:1 scale on 9x11 tiled sheets with assembly key, print-check square on every sheet. VERIFY BEFORE CUTTING: die-seat drive pin holes are match-drill — die patterns vary by maker and the die is shown reference only. Cheek-plate bolt pattern is a labeled design spec on the sheet.
