Roof Fan Mount Kit — UTV Roll Cage
True 1:1 template kit - Roof Fan Mount Kit — UTV Roll Cage: assembly views, dimensioned part sheets and a full cut list, drawn to the blueprint standard - print at 100% (2.00in print-check square on the sheet), trace, cut. Pure-geometry DXF cut file included. VERIFY ON VEHICLE: MEASURE YOUR CAGE TUBE OD AND ROOF PANEL POSITION BEFORE CUTTING - THE 10.000 x 10.000in FAN PLATE AND 1.750in STRAPS ARE DESIGN SPEC, CAGES AND ROOFS VARY. FAN IS BUILDER-SUPPLIED - SIZE THE PLATE HOLE TO YOUR FAN VERIFY ON VEHICLE: FAN MUST CLEAR EVERY HEAD WITH THE HARNESS TIGHT, THE GUARD MUST BE FITTED ON THE CAB SIDE, AND WIRING MUST BE FUSED AT THE BATTERY WITH NO CHAFE ON CAGE EDGES BEFORE DRIVING - DESIGN SPEC
