Mini Bike Build - Frame Geometry & Jig Layout

Master geometry and jig layout sheet for the Mini Bike Build fat-tire frame - an original PunchMapPro design drawn at literal 1:1. Side and top views give the full jig picture: 48.00in wheelbase, 30.0-degree head axis through the front axle center, 7.50in axle height, 6.13in ground clearance, 26.0in seat height. Includes the master coordinate table from the rear-axle ground datum, the engine plate zone and jig setup notes; the engine is a reference outline only. Ships as a print-ready tiled PDF (57 pages, Letter size, 0.5in overlap, numbered tiles with an assembly key) - print at 100% and tape the pages together. One flag rides on this sheet: the engine crank axis is shown nominal - VERIFY ON VEHICLE before final TAV setup (printed on the drawing).
